Õ-V SP COMPRESS 7000i AW CS 9 OR-s MONOBLOKK VÄLISOSA 3-9 KW

Features and benefits

• Height: AWMS models 1800mm
• Energy class A++
• Manufacturing country: Sweden
• Outdoor unit frame structure: 70mm expanded polypropylene (quiet)
• Domestic hot water output: 285l / 40C
• Integrated defrost tank in outdoor unit. No separate drain pan or defrost tank required
• WiFi remote control
• Five power classes enable selection of the correct heat pump capacity between 5kW and 17kW

Sizing

• Quick sizing (see attachment)
• Or contact your distributor

Optional accessories
Additional circuit control:

• MM100 / LVI 5360956 (includes return water sensor)
• 3-way valve 22mm + motor: LVI 5360933

Swimming pool module:

• MP100 / LVI 5360957

Room thermostat:

• CR10 LVI 5360958

For higher domestic hot water demand:

• For example, 300l electric booster connected in series

Connection methods

Radiator and floor heating:

• Buffer tank BC100 / LVI 5360916 with four-pipe connection. (Ensures outdoor unit defrost energy)
• AWM changeover valve 1" for working tank connection / LVI 5360969
• Cable for AWM changeover valve / LVI 5360972

One of the following:

• Heating cable 2m LVI 5360961
• Heating cable 3m / LVI 5360962
• Heating cable 5m / LVI 5360963

Fuse ratings for different electric heater powers:

• 9kW - 3 X 16A
• 12kW - 3 x 20A
• 15kW - 3 X 25A

BC100 / LVI 5360916 required if LTO post-heating radiator uses water

BC300 / LVI 5360917 required if space heating is via air heating

Indoor units for previous model

• LVI 5360950 / AWM 5-9 (Indoor unit with domestic hot water tank AW5 for outdoor unit) with 9kW resistor
• LVI 5360952 / AWB 5-9, Indoor unit next to oil boiler without domestic hot water tank AW5 for outdoor unit.
• LVI 5360954 / AWE 5-9, Indoor unit without domestic hot water tank with 9kW resistor for AW5 outdoor unit

Note! The outdoor unit does not require a separate drain pan or defrost tank.

This product description is an automated translation of the original Finnish description.
