KÜTTEKAABEL DEVIflex 10T 2050W 230V 210m

DEVIflex™ is a two-conductor heating cable with one connection cable. Use for floor/heating renovation floors: - concrete floor thickness is less than 5 cm - for ross and panel construction floors. Also suitable for freeze protection and pipe tracing heating. DEVIflex™ heating cable is suitable for use in both new construction and renovation projects: heating of concrete, wood, and panel structures (gypsum board and particleboard) as well as ross construction floors in homes, offices, public spaces, factories, schools, etc., with tile, plastic, cork, laminate, or wood finishes. The heating cable is supplied on a single-use reel in predetermined lengths, facilitating installation. The cable is marked with meter indicators. The power output of the DEVIflex™ 10T heating cable is 10 W/m. The installation spacing can vary between 17 and 6 cm, resulting in a power density of 60-150 W/m². In concrete floors, the typical power used is 100-120 W/m². In gypsum board floors, the power used is 80-100 W/m² (max. 100 W/m²). In ross construction floors, the power used is 60-80 W/m² (max. 80 W/m²). The heating cable can also be used for pipe tracing. The heating cable is attached to the pipe with aluminum tape at intervals of 25-30 cm, either single or double, depending on the required power. Features - operating voltage: 230 V - power per meter: 10 W/m - diameter: 6.9 mm - cable construction: round, shielded, two-conductor, one connection cable - connection cable: 2.3 m, DTCL, 3 x 1.5 mm² or 3 x 2.5 mm² - outer sheath: PVC - maximum ambient temperature: 65 °C - minimum installation temperature: -5 °C - minimum bending radius: 6 x cable diameter - conductor insulation: PEX - standards: SEMKO, CE, IEC60800:2009 This product description is an automated translation of the original Finnish description.
