LEEDTORU T5 7W 840 AC HE14 P 549MM

Tootekood
DKW901
LED TUBE T5 AC PERFORMANCE - comprehensive product family of T5 LED tubes designed for direct connection to mains voltage. Bypassing the ballast reduces the number of components in the fixture and simplifies maintenance. For AC-type LED tubes, the ballast must be removed from the luminaire and the tubes must be connected to 230 V mains voltage according to the installation instructions. Key technical specifications: • Luminous flux: 1100 lm (equivalent to T8 14 W) • Base: G5 • Operation: Only 230 V (AC) • Color temperature: 4000 K • Color rendering index: over 80 • Power: 7 W • Luminous efficacy: 157 lm/W • Energy efficiency class: D • Beam angle: 190° • Dimensions (length/diameter): 563 x 19 mm • Operating temperature: -20…+45 °C • Service life: 50,000 hours (L70/B50 +25 °C) • Warranty: 5 years • Certifications: CE • PET coating, shatterproof This product description is an automated translation of the original Finnish description.

Toote andmed

Tehnilised näitajad

Nimipinge220 - 240 V
Nimivool33 - 33 mA
Võimsustegur0.9
Lambi võimsus7 - 7 W
Pinge tüüpAC
Sobib elektroonilisele ballastileei
Sobib magnetilise liiteseadisegaei
Valgusvoog1100 - 1100 lm
Nimivalgusvoo vastavalt IEC 62612-le1100 lm
Lambi tõhusus157 lm/W
Värviesitusindeks CRI80-89
Lambi kujuToru, kahe otsaga
Lambi hõõgniitei
Material of light bulbKlaas
Klaasi/katte tüüpJää

Tootekoodid

SAPDKW901
PLC4099854552786
EAN/GTIN4099854552786
Tootja tootekood4099854552786
Tarnija tootekood4099854552786

Põhinäitajad

Mõõdud565 x 20 x 24 mm
Maht0.27 l
Kaal0.09 kg
Ühiktk
Pakendi suurused1 / 10 / 90 / 1080
Kogus pakendis
UNSPSC39101628
KaubamärkLEDVANCE

Seotud dokumendid (4)
